SLC Digital Programming Card Solink (controller-v5)

BRAND SOLINK

The Solink SLC Lite Digital Programming Card is a dedicated tool designed for advanced configuration of the Solink V5 Brushless Motor. Engineered to provide precise and intuitive adjustments, it allows users to customize motor speed and starting torque easily and safely.

Compatible exclusively with the Solink V5 Brushless Motor.
Not compatible with other Solink models or motors from other brands.

Key Features

• Speed Adjustment from 10,000 to 46,000 RPM:
  Allows motor speed to be set in 1,000 RPM increments.
  Default setting: 46,000 RPM (11.1V).
• Adjustable Starting Torque:
  The motor’s starting torque can be modified by adjusting the current (default value: 60%).
• Simple and Intuitive Interface:
  Button-based control system for quick and easy parameter adjustment.

Button Description

• M
  Short press: Select the parameter to be adjusted
  Long press: Quickly reconnect to the motor if disconnected
• –
  Short press: Decrease the selected value
  Long press: Rapidly decrease the selected value
• +
  Short press: Increase the selected value
  Long press: Rapidly increase the selected value
• S
  Long press: Save the settings to the motor

Operating Specifications

• Minimum battery voltage required: above 7.4V
• After saving the settings, the card automatically disconnects from the motor
• To reconfigure, power on the device again or press and hold the M button to reconnect

Safety Instructions
Always securely fix the motor before use to prevent accidental rotation.
Ensure the motor is properly connected to the programming card before powering it on.
Do not disconnect the motor wires while in the settings menu.
Make sure the ETU’s maximum current rating is compatible with the selected motor starting current. Any damage caused by incompatible settings is not covered.
